MemoryBlock

MemoryBlock

Theory

A MemoryBlock gives our BrainBlock extra memory. The MemoryBlock uses an SD Card.
This lets us do things such as:

  • Play sound files (music, voices, sound-effects, ring-tones, etc)
  • Record measurements to be used later

SD Cards are made of a special kind of memory called Flash Memory.  Flash memory is special because it can remember information even when the power is turned off.

Flash memory uses Floating Gate Transistors to store information.  They are sort of like balloons that you can store a static charge on; but an SD card has millions or billions of tiny static charges that are carefully protected and can last many years with the power off.

Connection Diagram

MemoryBloX

  1. SDSD
    Place SD card into the USB card adapter
    Plug adapter into your computer
    NOTE: The card just slides in and out - and doesn't go in any further than in the picture
  2. SDSDSD
    The SD card clicks in and out of the reader like clicking a pen
    Push in a little to click it out
